Zero deviation

Not exceeding ± 0.5% of the output range (zero point adjustable for split type products)

Zero point and range adjustment

±20%(Split type adjustable, integrated product not adjustable)

Range adjustment

Adjustable between small and large ranges (for split type products, the range of integrated products cannot be adjusted)

Power supply impact

Less than 0.01%/V of the output range

Load impact

Negligible

Temperature influence

-Within the range of 10 ℃ to+60 ℃: the variation is less than ± 0.1%/10 ℃ (0.1 level)

Change less than ± 0.15%/10 ℃ (0.2 level)

-30 ℃~-10 ℃, 60 ℃~+85 ℃: variation less than ± 0.15%/10 ℃ (0.1 level)

Change less than ± 0.20%/10 ℃ (0.2 level)

Stability

±0.25%FS/3year

Range of measurement

0～1m to 0～200m(Refer to the selection table)

Overload pressure

Twice the amount of travel

output signal

4～20mADC（two-wire）

working voltage

12V-36V DC

operation temperature

-20℃～60℃

Storage temperature

-40℃～80℃

load resistance

(4-20mA) Among them: U is the power supply voltage, RD is the internal resistance of the cable

Shell Material

304 (ordinary type and armored type)

Polytetrafluoroethylene (anti-corrosion type) (only applicable to 920 type)

Lead out line

Double layer wear-resistant waterproof ventilation cable (cable output integrated structure)

Or Φ 6 outer diameter stainless steel armored tube (armored type split structure)

Or Φ 7.5 outer diameter PTFE hose (anti-corrosion type split structure) (only applicable to 920 type)

Junction box

Low copper aluminum alloy surface spray treatment (integrated structure)

Indicator table

3-1/2LCD digital display (digital display, only for split type products)

Explosion proof sign

ExibⅡCT6

protection grade

Better than IP65
